  2. FANUC Series 16i/18i-MB/18i-MB5 Small-Hole Peck Rigid Tapping, Specifications

FANUC Series 16i/18i-MB/18i-MB5 Small-Hole Peck Rigid Tapping, Specifications Additional Manual Page 10

Additional Manual
2002/08/19 T.Inagaki
13411
Percentage of cutting feedtrate to be changed after over-torque
[Data type] Byte
[Unit of data] %
[Data range] 0～100
This parameter sets the percentage of cutting feedtrate to be changed after an
over-torque signal is received in a small-hole peck rigid-tapping.
β=α×d1÷100
α：The override value before the change of the override value.
β：The override value after the change of the override value.
d1：This parameter value [%]
Caution
1. This parameter is available only on small-hole peck rigid-tapping, and
not available on the normal peck rigid tapping.
2. Every cycle, the change of override by this parameter is executed on
point R.
13412
Percentage of cutting feedtrate to be changed without over-torque
[Data type] Byte
[Unit of data] %
[Data range] 0～100
This parameter sets the percentage of cutting feedtrate to be changed (without
receiving an over-torque signal) in a small-hole peck rigid-tapping.
β=α×d2÷100
α：The override value before the change of the override value.
β：The override value after the change of the override value.
d2：This parameter value [%]
Caution
1. This parameter is available only on small-hole peck rigid-tapping, and
not available on the normal peck rigid tapping.
2. Every cycle, the change of override by this parameter is executed on
point R.
A-78641EN
FANUC Series 16i/18i–MB/18i–MB5
Small-hole peck rigid tapping
Title
Drawing No.
Page
Descri
p
tionDate Edit
10/14
Previous page
Next page
