FANUC Series 16i/18i-MB/18i-MB5 Small-Hole Peck Rigid Tapping, Specifications Additional Manual Page 8

Additional Manual
2002/08/19 T.Inagaki
2. Signals and parameters
Signals
Over torque signals
SKIP<X004#7>
OLDTS <G275#7>
[Classification] Input signal
[Function] Retracts a tool if an overload torque is applied.
[Operation] When this signal becomes "1", the control unit operates as follows:
• Assuming that an overload torque is applied to a tool, retracts it, and
changes the spindle speed and cutting feedrate, then retries tapping.
• This signal is valid, when the tapping axis is between points R and Z and
is moving forward or in cutting operation (so that the tool can retract).
NOTE
1. The signal SKIP(X004#7) is used also as a skip signal.
2. The signal OLDTS(G275#7) is effective only when parameter
No.13400#2(OTD) is set to '1'.
Small-hole peck rigid-tapping in
progress signal PECK3 <F275#7>
[Classification] Output signal
[Function] Indicates whether small-hole peck rigid-tapping is in progress.
[Output condition] This signal becomes "1" under the following conditions.
• When the tool returns from drill axis point R positioning to R
point/initial level, after it was positioned at the hole position along a
nondrill axis.
Signal address
#7 #6 #5 #4 #3 #2 #1 #0
X004 SKIP
#7 #6 #5 #4 #3 #2 #1 #0
G275 OLDTS
#7 #6 #5 #4 #3 #2 #1 #0
F275 PECK3
A-78641EN
FANUC Series 16i/18i–MB/18i–MB5
Small-hole peck rigid tapping
Title
Drawing No.
Page
Descri
p
tionDate Edit
8/14
