  2. FANUC Series 16i/18i-MB/18i-MB5 Small-Hole Peck Rigid Tapping, Specifications

FANUC Series 16i/18i-MB/18i-MB5 Small-Hole Peck Rigid Tapping, Specifications Additional Manual Page 9

Additional Manual
2002/08/19 T.Inagaki
Parameters
#7 #6 #5 #4 #3 #2 #1 #0
13400
OTD NOL OLR
[Data type] Bit
OLR When over torque signal is detected, the override value for rigid-tapping is:
0: not changed.
1: changed.
NOL When cutting is reached to the depth of cut per action without the detection
of over torque signal, the override value for rigid-tapping is:
0: not changed.
1: changed.
OTD On small-hole peck rigid-tapping mode, over torque signal
G275#7(OLDTS) is:
0: not effective.
1: effective.
13410
M code that specifies small-hole peck rigid-tapping cycle mode
[Data type] 2-word
[Data range] 1～99999999
This parameter sets an M-code that specifies small-hole peck rigid tapping
mode. And this M code (No.13410) can become common to the M code
specifying rigid tapping mode (No.5210 or No.5212).
