Open CNC Screen Display Function Operators manual Page 72

Operators manual
B.CNC SCREEN DISPLAY FUNCTION FOR THE FS160is/180is/210is APPENDIX B-63164EN/04
- 56 -
B.1 INSTALLING THE CNC SCREEN DISPLAY FUNCTION
The HSSB version of the CNC screen display function has been
preinstalled in the FS160is/180is/210is. Usually, it need not be
installed again. To upgrade it or install the Ethernet version, follow
the steps below.
Procedure for installing the CNC screen display function
(1) Copy the following file (self-extracting form) to an empty folder
on a development personal computer and execute.
[MODEL A (A02B-0207-K771#ZZ07) for HSSB]
WinCE200.exe for WindowsCE2.0
WinCE212.exe for WindowsCE2.12
[MODEL A (A02B-0207-K773#ZZ07) for Ethernet]
CSDFEis.exe for WindowsCE2.0
[MODEL B (A02B-0207-K774)]
CSDFWCE300.exe for WindowsCE3.0
(2) "CNCScrn" folder and "Setupis.exe" file will be melted.
(In case of CSDFEis.exe, only "CNCScrnE" will be melted.)
(3) Copy "Setupis.exe" and the "CNCScrn" (or "CNCScrnE") folder
to an ATA card.
(4) Switch on the CNC.
(5) Insert the ATA card into the PCMCIA slot of the
FS160is/180is/210is.
(6) Open My Computer on the desktop, and check that the ATA card
is automatically recognized as "Storage Card2."
(7) Open "Storage Card2" and start Setupis.exe.
(8) Check the check box for "CNCScrn" (or "CNCScrnE") to be
installed, and choose the "OK" button or press the "INPUT" key.
NOTE
1 Inserting an ATA card having a copy of a program
into the CNC, then switching it on causes
"Setupis.exe" to start automatically. After the
function is installed, remove the ATA card, and
switch the CNC off and on again.
2 To uninstall the function, delete the following folder.
¥Storage Card¥FANUC¥CNCScrn
