Open CNC Screen Display Function Operators manual Page 81

Operators manual
B-63164EN/04 APPENDIX B.CNC SCREEN DISPLAY FUNCTION FOR THE FS160is/180is/210is
- 65 -
B.9 TERMINATION BY MEANS OF THE MACHINE SIGNAL
(ETHERNET VERSION ONLY)
Turning on a specified machine signal terminates the CNC screen
display function. To specify the machine signal, follow the procedure
below.
(1) Choose the [Close Signal...] from the [Option] menu. A dialog
box for specifying the signal appears.
(2) Enter the target PMC signal in the Signal on host text box, using
the following format, then choose "OK."
<signal-address>.<bit-position> Example) X0003.7
NOTE
1 The setting of the machine signal is preserved. It is
impossible to start the CNC screen display function
if the set signal is kept turned on with the PMC
sequence program.
2 The signal for the PMC connected via a local bus or
HSSB can be specified at the same time. In this
case, make settings also for the signal on the
HSSB side. If the PMC signal is specified as both
signal on the host side and signal on the HSSB
side, the CNC screen display function is terminated
when the PMC signal on either side becomes on.
