Series 16i/18i/21i/160i/180i/210i-Model A Startup Guide Page 45

Startup Guide
2 - 4 16
i
/18
i
/21
i
Startup Guide - May 2000
B-
63003EN-2/01
2
Parameter Write Enable (PWE)
Before you can begin entering any parameter values, you must turn on the Parameter Write
Enable(PWE) bit. PWE is the built-in software write protect feature which prevents any
accidental changes to you parameter values once they have been set.
In order to turn on PWE, enter the following keystrokes:
1
.
Press the [OFFSET SETTING] hard key.
2
.
Press the (SETING) soft key option. This will bring you to the handy setting screen
(see Figure 2-1 below).
SETTING (HANDY)
PARAMETER WRITE =
0 (0 : DISABLE 1 :
ENABLE)
TV CHECK = 0 (0 : OFF 1 : ON)
PUNCH CODE = 0 (0 : EIA 1 : ISO)
INPUT UNIT = 0 (0 : MM 1 : INCH)
I/O CHANNEL = 0 (0-3 : CHANNEL NO.)
SEQUENCE NO. = 0 (0 : OFF 1 : ON)
TAPE FORMAT =
0 (0 : NO CNV 1 :
F10/11)
SEQUENCE STOP = 0(PROGRAM NO.)
SEQUENCE STOP = 0(SEQUENCE NO.)
CONTRAST ( + = [ ON : 1 ] - = [ OFF : 0 ])
Figure 2 - 1. Handy setting screen
3
.
The cursor should already be on the PWE bit. From the MDI panel, press [1] followed
by [INPUT] to turn on PWE. You will see that the following alarm message appears on
your screen:
100 PARAMETER WRITE ENABLE
This alarm will appear every time you power up the control until you go back and turn
off the bit. However, since you still need to set some other parameters, you can ignore
it for now and use the [RESET] + [CAN] keys to remove the alarm after each power-up.
Both keys must be pressed at the same time.
