Series 16i/18i/21i/160i/180i/210i-Model A Startup Guide Page 61

Startup Guide
B-63003EN-2/01 3 - 1
Chapter
Installing the Startup Ladder
By now, you should have connected the control to the entire machine tool control system and set the
basic parameters. However, you still need a ladder . . .
This chapter outlines the steps necessary to load the startup ladder onto your control.
Caution
Please remember that this ladder was provided only as a developmental tool to
help you get the motors running. It is by no means a completely “functional”
ladder. However, it will give you a starting point from which you can then
customize it to suit your machine’s specific application.
Before loading the ladder, please take note of the following items:
• We have provided the ladder files to you on a 3 ½” floppy disk. In order to load a ladder
onto your control, you will need an SRAM card and a PC with a PCMCIA card drive. The
file must be copied onto the SRAM card before it can be used on the control.
GE Fanuc offers the following two SRAM cards:
A87L-0001-0150/2M
2 Megabyte
A87L-0001-0150/4M
4 Megabyte
Note:
Lithium battery type CR2025 or similar is required
• If you have chosen to provide your own operator’s panel, you will have to develop the entire
ladder yourself. Being that this is a startup guide, this chapter does not include a discussion
on ladder editing. If you would like more information on the specifics of ladder language
programming, please refer to the GE Fanuc PMC Model
PA1/PA3/RA1/RA2/RA3/RB/RB2/RB3/RB4/RB5/RB6/RC/RC3/RC4/NB/NB2 Ladder
Language Programming Manual (publication no. B-61863E).
3
Previous page
Next page
