PROGRAMMING 2. CONTROLLED AXES

B–63514EN/01

The increment system consists of the least input increment (for input) and

least command increment (for output). The least input increment is the

least increment for programming the travel distance. The least command

increment is the least increment for moving the tool on the machine. Both

increments are represented in mm, inches, or deg.

The increment system is classified into IS–B and IS–C. Select IS–B or

IS–C using bit 1 (ISC) of parameter 1004. The setting of bit 1 (ISC) of

parameter No.1004 applies to all axes. When IS–C is selected, for example,

the increment system for all axes is set to IS–C.

Name of in-

crement sys-

tem

Least input incre-

ment

Least command

increment

Maximum

stroke

IS–B

0.001mm

0.0001inch

0.001deg

0.001mm

0.0001inch

0.001deg

99999.999mm

9999.9999inch

99999.999deg

IS–C

0.0001mm

0.00001inch

0.0001deg

0.0001mm

0.00001inch

0.0001deg

9999.9999mm

999.99999inch

9999.9999deg

The least command increment is either metric or inch depending on the

machine tool. Set metric or inch to the parameter INM (No.100#0).

For selection between metric and inch for the least input increment, G

code (G20 or G21) or a setting parameter selects it.

Combined use of the inch system and the metric system is not allowed.

There are functions that cannot be used between axes with different unit

systems (circular interpolation, cutter compensation, etc.). For the

increment system, see the machine tool builder’s manual.

2.3

INCREMENT SYSTEM
