QuickTurn Electronic Lathe Connection manual (Hardware) Page 8

Connection manual (Hardware)
QuickTurn™
GFKE-0201B-EN - 8 - GE Fanuc Automation S.A.
Spindle
• Analog spindle driven by frequency converter available on the marked
All spindles available for 0i Mate TB are supported by Quick Turn
Cable Material
• A02B-0236-K85* (*= 1, 2, 3, 4, 5, 6) Optical Fiber Cables for Beta I Amplifier Connection
• LX660-2007-T010/L*R003 I/O Link Cable for I/O Module Connection
• LX660-4077-T292/L*R03 Encoder Cable for Servo Motor
• LX660-4078-T021/L*R03 Power Cable for Servo Motor
• LX660-4024-T030/ Cable for Connecting Quick Panel To 0i Mate TB
• LX660-8024-T010/ Power Supply 24V Cable
• LX660-8018-T002 Manual Pulse Generator Cable for 3 MPG
• LX660-8078-T011/ Power Supply 24V to Beta SVM1-20i
• LX660-8078-T008/ Power Supply 220 V AC 3 Phase to Beta SVM1-20i
• A06B-6130-H401 (or –H402) Discharge Resistor
• LX660-8078-T010/ Magnetic Contactor MCC Connection Cable to Beta SVM
• LX660-8078-T009/ Emergency Stop Connection to Beta SVM1-20i
• LX660-2078-T001/ Power Connection 24 V Between 2 Beta SVM1-20i
For starting up Quick Turn additional software and hardware is needed. This software and hardware is
needed only for starting up Quick Turn once the system is running material is needed only for maintenance
purposes. The material used for start up can be used for starting up multiple machines. For overview of
material needed for start up refer to “Quick Turn Start Up Manual”.
NOTE
WARNING
