1. PARAMETERS OF THE PRESS FUNCTION
9
Address
16033
Time interval by which the start of the next bolck follows setting of *PFIN to
0 in the forming mode
Data type: Byte
Unit of data: msec
Valid data range: 0 to 248
Parameter 16033 sets the time interval by which the start of the next block
follows setting the contact of the *PFIN signal to complete punching for
single–cycle pressing to 0 in the forming mode.
Positioning
Time set in
parameter
16032
Next block
Time set in
parameter
16033
PF
*PFIN
Address
16034 Time interval by which setting PF to 1 follows first positioning in nibbling
Data type: Byte
Unit of data: msec
Valid data range: 0 to 248
Parameter 16034 sets the time interval by which setting the PF signal to
start pressing to 1 follows positioning at the first punch point in nibbling
(nibbling by G68, G69, and M code).
Address
16035
Time interval by which the start of the next block follows setting *NFIN to 0
at the last positioning in nibbling
Data type: Byte
Unit of data: msec
Valid data range: 0 to 248
Parameter 16035 sets the time interval by which the start of the next block
follows setting the contact of the *NFIN signal to complete punching for
continuous pressing to 0 at positioning at the last punch point in nibbling
(nibbling by G68, G69, and M code).
