Synchronous Spindle Motor
Mounting Sensor/Starting sequence
Specification
rotation depends on initial position at the time.
•Alarm 65 is issued when the rotation angle from 0 to 90 degrees position amount less than 80
degrees after confirming the stall at 90 degrees position. This might happen if the motor is locked up
mechanically. If so, release it to move the motor after power off.
(2)After the temporary pole setting, the velocity command can drive the motor. In case of EPFSTR
method as the trigger, the operator can issue the velocity command after identifying the temporary
pole setting.
(3)The pole detection completed with the pole position set to zero where it detects a reference signal of
BZ sensor.
Unexpected behavior during the pole detection
As described former, Using SFR/SRV as the trigger may seem to be irregular motion for a operator
who is not aware of the pole detection because of irrelevant behavior to his will. The pole detection
method using EPFSTR and EPFIX is prepared for them who doesn’t prefer the situation.
(Note) This pole detection sequence is subject to the change or the modification without notice in
advance for purpose of improving the performance.
