FANUC Series 30i-MODEL A
Input of tool offset value measured B
5053
Bias for tool offset numbers for measured tool offset
value setting
[Input type] Parameter input
[Data type] Word path
[Valid data range] 1 to maximum tool offset count
When the tool setter function for 1–turret, 2–spindle lathes is used, this parameter
allocates tool offset numbers for measured tool offset measurement values to pindle
1 and spindle 2.
Example:
When the tool offset count is 32 pairs
Tool offset number
8 10
Spindle 1
1
～
8 1
～
10
Spindle 2
9
～
32 11
～
32
If 0 is set for this parameter, or if the maximum tool offset count is exceeded, the
following is assumed:
Tool offset
number
32pairs 64 pairs 99 pairs 200 pairs
Spindle 1
1
～
16 1
～
32 1
～
49 1
～
100
Spindle 2
17
～
32 33
～
64 50
～
98 101
～
200
Tool offset
number
400 pairs 499 pairs 999 pairs
Spindle 1
1
～
200 1
～
249 1
～
499
Spindle 2
201
～
400 250
～
498 500
～
998
5054
Workpiece coordinate system memory for spindle 1
5055
Workpiece coordinate system memory for spindle 2
[Input type] Parameter input
[Data type] Byte path
[Valid data range] 54
～
59
When the WNI parameter (bit 1 of parameter No.5051) is set to 1 specify, in each
of these parameters, a workpiece coordinate system from G54 to G59 for workpiece
reference point offset value setting.
Note
This is valid if the 2AT parameter (bit 1 of parameter
No.5051) is 1.
