FANUC SERVO AMPLIFIER βi series
I/O Link option
DESCRIPTIONS
15 /
2.6.2 When a Separated Regenerative Discharge Resistor is Needed by
SVM1-4 i and SVM1-20 i.
If the amount of energy regenerated per regeneration cycle exceeds the
maximum amount of energy that a servo amplifier can handle, a DC link
over-voltage alarm occurs. In this case, a separated regenerative
discharge resistor is needed.
Note in mind that an incorrect connection can damage the
amplifier.
Selecting a regenerative discharge resistor
First obtain how much regenerative energy occurs.
- For horizontal movement
(1) Servo motor (for horizontal movement)
Amount of regenerative discharge (power [W]) when rapid traverse
acceleration/deceleration is performed once every F sec
(a) SI unit system
４
）
（ExpressionWTLVmtaVmJLJm
F
w ][)1023.5)(1048.5(
1
2
23
⋅⋅⋅×−⋅+⋅××=
−
−
F : Frequency of rapid traverse acceleration/deceleration
[sec/number of times]
Unless otherwise specified, rapid traverse acceleration/deceleration is
assumed to be performed about once every 5 seconds.
Jm: Rotor inertia of the motor [kg･m
2
]
JL: Motor-shaft-converted inertia of the load [kg･m
2
]
Vm: Motor speed at rapid traverse [min
-1
]
ta: Rapid traverse acceleration/deceleration time [sec]
TL: Machine frictional torque (motor-converted value) [N･m]
(b) CGS unit system
４
）
（ExpressionWTLVmtaVmJLJm
F
w ][)1013.5)(1037.5(
1
324
⋅⋅⋅×−⋅+⋅××=
−−
F : Frequency of rapid traverse acceleration/deceleration
[sec/number of times]
Unless otherwise specified, rapid traverse acceleration/deceleration is
assumed to be performed about once every 5 seconds
Jm: Rotor inertia of the motor [kgf･cm･sec
2
]
JL: Motor-shaft-converted inertia of the load [kgf･cm･sec
2
]
Vm: Motor speed at rapid traverse [min
-1
]
ta: Rapid traverse acceleration/deceleration time [sec]
TL: Machine frictional torque (motor-converted value) [kg･cm]
