FANUC SERVO AMPLIFIER ßi series I/O Link option Additional Manual Page 77

Additional Manual
A
-77223E/02
図
番
名
称
ペ
｜
ジ
変更内容 設計 年月日
版
FANUC SERVO AMPLIFIER βi series
I/O Link option
DESCRIPTIONS
77 /
6 HEAT DISSIPATION
The amount of heat dissipation depends on the SVM model and the
current that flows through the servo motor. For the current that flows
through a servo motor, reference the continuous rated current of each
servo motor. (For the continuous rated current of each servo motor, refer
to the servo motor descriptions.) As the current that flows through a
servo motor, the root-mean-square value of the current that flows
through an actual servo motor on a machine can be used. The amount
of heat dissipation indicated below assumes the use of HRV2.
(1) Total amount of heat dissipation
The total amount of heat dissipation is calculated according to the
following expression:
Total amount of heat dissipation = a + Ka1 × b1
a: Amount of heat dissipation determined by the SVM model [W]
Ka1: Coefficient determined by the SVM [W/Arms]
b1: Current flowing through the servo motor [Arms]
Total amount of heat dissipation
Name Specification
a
[W]
K
[W/Arms]
SVM1-4i
H001 20 Ka1: 8.1
SVM1-20i
H002 20 Ka1: 7.7
SVM1-40i
H003 20 Ka1: 7.1
SVM1-80i
H004 20 Ka1: 6.7
