AC SPINDLE MOTOR Alpha series Descriptions Page 140

Descriptions
4. ORDERING NUMBER
B–65152E/03
FANUC AC SPINDLE MOTOR α (HV) series
140
4
ORDERING NUMBER
(1)a (HV) series
Name Ordering number Remarks
Model a 6HV Flange mounting A06B–0874–B100
A06B–0874–B101
A06B–0874–B300
A06B–0874–B301
8000 min
–1
, has key, exhaust rear
8000 min
–1
, has key, exhaust front
8000 min
–1
, no key, exhaust rear
8000 min
–1
, no key, exhaust front
Foot mounting A06B–0874–B200
A06B–0874–B201
A06B–0874–B400
A06B–0874–B401
8000 min
–1
, has key, exhaust rear
8000 min
–1
, has key, exhaust front
8000 min
–1
, no key, exhaust rear
8000 min
–1
, no key, exhaust front
Model a 8HV Flange mounting A06B–0875–B100
A06B–0875–B101
A06B–0875–B300
A06B–0875–B301
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
Foot mounting A06B–0875–B200
A06B–0875–B201
A06B–0875–B400
A06B–0875–B401
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
Model a 12HV Flange mounting A06B–0876–B100
A06B–0876–B101
A06B–0876–B300
A06B–0876–B301
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
Foot mounting A06B–0876–B200
A06B–0876–B201
A06B–0876–B400
A06B–0876–B401
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
Model a 15HV Flange mounting A06B–0877–B100
A06B–0877–B101
A06B–0877–B300
A06B–0877–B301
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
Foot mounting A06B–0877–B200
A06B–0877–B201
A06B–0877–B400
A06B–0877–B401
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
Model a 18HV Flange mounting A06B–0878–B100
A06B–0878–B101
A06B–0878–B300
A06B–0878–B301
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
Foot mounting A06B–0878–B200
A06B–0878–B201
A06B–0878–B400
A06B–0878–B401
6000 min
–1
, has key, exhaust rear
6000 min
–1
, has key, exhaust front
6000 min
–1
, no key, exhaust rear
6000 min
–1
, no key, exhaust front
NOTE
1 The listed ordering numbers are for motors with a M sensor. The end of the ordering number
for the motor with a MZ sensor is B 9 .
2 Refer to the ordering list (B–65151E) for available motors except above.
