AC SPINDLE MOTOR Alpha series Descriptions Page 21

Descriptions
B–65152E/03
3. MOTOR TYPES
BCATLTLON EOT TFC α
21
The following main functions require the motor(s) listed below:
`Spindle orientation by a position coder
– Motor with a built–in M sensor + spindle α position coder
– Motor with a built–in M sensor + spindle BZ sensor
– Motor with a built–in MZ sensor
NOTE
For the resolution of each motor with a built–in MZ sensor,
refer to the related series specifications.
`Spindle orientation by an external one–rotation signal
– Motor with a built–in MZ sensor + external one–rotation signal
switch
`Spindle orientation by a magnetic sensor
– Motor with a built–in M sensor + spindle magnetic sensor
`Rigid tapping
– Motor with a built–in M sensor + spindle α position coder
– Motor with a built–in MZ sensor
`Cs contour control
– Motor with a built–in MZ sensor + spindle BZ sensor
– Motor with a built–in MZ sensor + spindle α position coder S
`Spindle synchronization
– Motor with a built–in M sensor + spindle α position coder
NOTE
The αC series spindle motors can also support spindle
orientation by a position coder, rigid tapping, and spindle
synchronization.
For details, refer to SERVO AMPLIFIER α series
DESCRIPTIONS (B–65162E).
