  2. FANUC Series 30i/31i/32i -MODEL A Overwrite to the Same Name File on Memory Card

FANUC Series 30i/31i/32i -MODEL A Overwrite to the Same Name File on Memory Card Additional Manual Page 5

Additional Manual
A-90101E
Title
Draw
No.
Ed. Date Design Description
Date Aug..04.’05 Design. Apprv.
4/ 7
page
FANUC Series 30i/31i/32i -MODEL A
Overwrite to the same name file
on memory card
Periodical maintenance data
(Periodical maintenance : status screen)
MAINTENA.TXT
Tool management data(Tool management function) TOOL_MNG.TXT
Magazine data (Tool management function) MAGAZINE.TXT
Tool life status name data (Tool management function) STATUS.TXT
Name data of customize data
(Tool management function)
CUSTOMIZ.TXT
2nd geometory tool offset SEC_GEOM.TXT
Three-dimensional error compensation data COMP3D.TXT
Rotary table dynamic fixture offset FIXTURE.TXT
Customized data displayed as Tool management data
(Tool management extension function)
DISPCSTM.TXT
Spindle waiting position name data
(Tool management extension function)
POSNAME.TXT
Decimal point position data of customize data
(Tool management extension function)
POINTPOS.TXT
Realtime custom macro variable RTMMACRO.TXT
System configuration data SYS-CONF.TXT
PMC signal protection DIDOENBL.TXT
Tool geometory data
(Tool management function oversize tools support)
TOOLGEOM.TXT
Cause data (Tool in/out management function) TLCAUSE.TXT
Tool-in history data (Tool in/out management function) TLATAHIS.TXT
Tool-out history data (Tool in/out management function) TLDTAHIS.TXT
Servo / spindle information SV_SP_ID.TXT
Waveform diagnosis data WAVE-DGN.TXT
Tool geometory data (Tool post interference check) TOOL-FRM.TXT
Machine item name data
(Periodical maintenance : machine screen)
MAINTEMC.TXT
P code variable PCODE.TXT
Learning control data(Parts learning control) PRT_LN.TXT
Learning control data (Learning control) LEARN.TXT
High-precision pitch error compensation UPEC.TXT
Previous page
Next page

Contents Summary of FANUC Series 30i/31i/32i -MODEL A Overwrite to the Same Name File on Memory Card Additional Manual

  • Page 1TECHNICAL REPORT (MANUAL) ＮＯ．ＴＭＮ ０６／006E Date 13th, January, 2006 General Manager of Software Research Laboratory FANUC Series 30i/300i/300is-A FANUC Series 31i/310i/310is-A FANUC Series 31i/310i/310is-A5 FANUC Series 32i/320i/320is-A Function of overwrite to the same name file on memory card １．Comm
  • Page 2FANUC Series 30i/31i/32i-MODEL A Overwrite to the same name file on memory card Specifications ＜Table of contents＞ 1.1 OUTLINE ....................................................................................................................................... 2 1.2 EXPLANATION ...................
  • Page 31.1 Outline Outline When the operator tries to output the CNC data like parameter or program, and the file of the specified name already exists on the memory card, the operator can select whether the file is overwritten or not by the operation. This function becomes available by setting of parameter
  • Page 41.2 Explanation Display on screen When the outputting of CNC data to the memory card is executed, the confirmation message of "OVERWRITE?" is displayed when the specified file name or the default file name accords to the file name in the memory card. Fig1.2 (a) Example of screen display Data that ca
  • Page 5Periodical maintenance data MAINTENA.TXT (Periodical maintenance : status screen) Tool management data(Tool management function) TOOL_MNG.TXT Magazine data (Tool management function) MAGAZINE.TXT Tool life status name data (Tool management function) STATUS.TXT Name data of customize data CUSTOMIZ.TX
  • Page 61.3 Operation Procedure The procedure to output data is as follows on the screen of each function. 1. Press soft key [PUNCH]. 2. Press soft key [EXEC]. When the file of same name doesn't exist in the memory card, it is output at this time. 3. When the file of same name exists in the memory card, sof
  • Page 7Fig1.3 (c) Display of soft key after pressing [EXEC] Ex.) Outputting on parameter screen（In case of 15” display unit） 1. Press function key . 2. Press vertical soft key [PARAM]. 3. Press the EDIT switch on the machine operator’s panel or enter emergency stop state. 4. Press horizontal soft k
  • Page 81.4 Parameter #7 #6 #5 #4 #3 #2 #1 #0 11308 COW [Input type] parameter input [Data type] Bit #1 COW When the file of specified name already exists on memory card, 0: It is not overwritten Alarm (SR1973 FILE ALREADY EXIST) is generated. 1: It is overwritten. Note When the overwritten file is read onl
