FANUC Series 30i/31i/32i -MODEL A Overwrite to the Same Name File on Memory Card Additional Manual Page 8

Additional Manual
A-90101E
Title
Draw
No.
Ed. Date Design Description
Date Aug..04.’05 Design. Apprv.
7/ 7
page
FANUC Series 30i/31i/32i -MODEL A
Overwrite to the same name file
on memory card
1.4 Parameter
#7 #6 #5 #4 #3 #2 #1 #0
11308 COW
[Input type] parameter input
[Data type] Bit
#1 COW When the file of specified name already exists on memory card,
0: It is not overwritten
Alarm (SR1973 FILE ALREADY EXIST) is generated.
1: It is overwritten.
Note
When the overwritten file is read only attribute, it is not possible to
overwrite even if parameter COW (No.11308#1)=1.
1.5 Alarm
Number Message Description
SR1973 FILE ALREADY EXIST A file having the same name already exists on the
memory card.
1.6 Warning
Message Description
OVERWRITE？
A file having the same name already exists on the
memory card.
