I/O LINK II Connection manual Page 109

Connection manual
B-62714EN/04 CONNECTION 1.COMMUNICATION FUNCTION CONNECTION
- 97 -
1 COMMUNICATION FUNCTION
CONNECTION
This chapter provides information required for I/O Link-II connection.
CAUTION
For conditions on using equipment other than the
board, contact the manufacturer of the equipment.
For network installation, care must be taken to
protect against noise sources. Provide a sufficient
space to separate noise sources such as power
lines and motors electrically from the network
cabling, and also ground each device. If the
impedance of ground is too high for sufficient
grounding, a communication error can occur. Before
actual operation after equipment installation,
conduct a communication test for confirmation.
FANUC is not liable for network trouble that arises
from equipment other than the board.
