I/O LINK II Connection manual Page 56

Connection manual
2.LCD-MOUNTED TYPE 16i/18i/21i-A, Power Mate i-D/H OPERATION B-62714EN/04
- 44 -
2 LCD-MOUNTED TYPE 16i/18i/21i-A,
Power Mate i-D/H
This chapter describes the setting procedure for operating the master
function and slave function.
NOTE
Notes on PMi-D/H
-With PMi-D/H, only the slave function can be
used.
-With PMi-D/H, the I/O Link-II board (A20B-8100-
0310) and I/O Link-II board B (A20B-8100-0381)
can be used.
This chapter provides descriptions based on the
use of I/O Link-II B. When using the I/O Link-II
board, the same specifications as for Power
Mate-D/F/H described in Chapter 3 are
applicable. So, see Chapter 3.
