I/O LINK II Connection manual Page 86

Connection manual
2.LCD-MOUNTED TYPE 16i/18i/21i-A, Power Mate i-D/H OPERATION B-62714EN/04
- 74 -
30111 Internal relay address of the start of DO
[Input type] Parameter input
[Data type] Word
[Valid data range] Set 82 as R.
30112 Internal relay offset of the start of DO
[Input type] Parameter input
[Data type] Word
[Valid data range] 0 to 9999
30113 DI byte length
[Input type] Parameter input
[Data type] Word
[Valid data range] 0 to 128(Caution)
Set a DI data area size.
CAUTION
When using the global I/O transfer function, ensure
that the DI data size and DO data size of each slave
station on the network do not exceed 48 bytes.
NOTE
When any of the parameters above is modified,
alarm 000 (power-off request) is issued. So, the
power must be turned off then back on. A modified
parameter value does not become effective until the
power is turned off then back on.
