I/O LINK II Connection manual Page 95

Connection manual
B-62714EN/04 OPERATION 3.Power Mate-D/F/H
- 83 -
3.1 SLAVE FUNCTION
Setting parameters
Parameters
0171 DI byte length
[Input type] Parameter input
[Data type] Byte
[Valid data range] 0 to 32: Set a DI data area size when the DI/DO data transfer
function is used.
0 to 48: Set a DI data area size when the global I/O transfer function
is used.
Set a DI data area size.
0172 DO byte length
[Input type] Parameter input
[Data type] Byte
[Valid data range] 0 to 32: Set a DO data area size when the DI/DO data transfer
function is used.
0 to 48: Set a DO data area size when the global I/O transfer
function is used.
Set a DO data area size.
CAUTION
When using the global I/O transfer function, ensure
that the DI data size and DO data size of each slave
station on the network do not exceed 48 bytes.
0173 Local station number
[Input type] Parameter input
[Data type] Byte
[Valid data range] 1 to 31(Note)
Set the station number of the local station.
NOTE
When using the global I/O transfer function, set
slave station numbers sequentially to allocate an
area efficiently.
