I/O LINK II Connection manual Page 97

Connection manual
B-62714EN/04 OPERATION 3.Power Mate-D/F/H
- 85 -
0187 Internal relay address of the start of communication status
[Input type] Parameter input
[Data type] Word
[Valid data range] 0 to 999
Set the start address of communication status (R area of the PMC).
0 :Communication status is not allocated in a R area of the
PMC.
1 to 999 :Communication status is allocated in a R area of the PMC.
NOTE
For communication status, a 32-byte area is
allocated from the specified internal relay address of
the start of communication status.
0188 Master station communication monitoring time
[Input type] Parameter input
[Data type] Word
[Valid data range] 0 to 1000
Set a time-out value used when no DI data is sent from the master
station.
0 : 300 ms
1 to 1000 : 1 to 1000 ms
