GFK-1546 Chapter 2 FSSB Setting Screens 2 - 3
2
The following information is displayed on the Amplifier Setting screen:
Table 2 - 1. Amplifier Setting Screen Information
Item Name Description
NO. Slave Number
Each slave is assigned a number from 1 to 10, according to its
distance from the CNC.
AMP Amplifier Type
The amplifier type consists of the letter A for Amplifier plus a
number which shows its order in the list of amplifiers and an
alphabetic character representing the axis number in the amplifier
(L for the first axis, or M for the second axis). For example:
A2-L : the first axis of the second amplifier.
AXIS Axis Number The axis number set in parameters (No. 1920 - 1929) is
displayed. If the value set in the parameter is out of range (from 1
to the maximum number of controlled axes), a 0 is displayed.
NAME Axis Name The axis name (parameter No. 1020) is displayed.
Amplifier Information
UNIT Unit Kind of Servo Amplifier Unit.
SERIES Series Servo Amplifier Series.
CUR. Current Maximum current.
Pulse Module Information
EXTRA Order
The letter M for Pulse Module plus a number which shows its
order in the list of pulse modules
TYPE Pulse Module Type An alphabetic character representing the pulse module type is
displayed.
PCB ID Pulse Module ID The pulse module ID is displayed in hexadecimal.
If the pulse module is supplied for 4 axes,
"DETECTOR(4AXES)" is also displayed.
If two pulse modules are supplied for 8 axes,
"DETECTOR(8AXES)" is displayed.
