ALPHA Series Servo Amplifier Module (SVM) With FSSB Startup Guide Page 31

Startup Guide
3 - 8 Alpha Series Servo Amplifier Unit (SVM) with FSSB - April 1998 GFK-1546
3
4. Enter the axis number on the Amplifier Setting screen.
AMPLIFIER SETTING
NO. AMP SERIES UNIT CUR. [AXIS] NAME
1 A1-L α SVM 40A [ 2 ] Y
2 A2-L α SVM 40A [ 1 ] X
3 A3-L α SVM 40A [ 4 ] A
4 A3-M α SVM 80A [ 3 ] Z
NO. EXTRA TYPE PCB ID
>
MDI **** *** *** 13:11:56
[ AMP ] [ AXIS ] [MAINTE ] [ ] [(OPRT) ]
5. Press the [SETING] soft key.
6. Press the SYSTEM function key.
7. Press the > key several times to display the [FSSB] soft key. Then, press the
[FSSB] soft key to change the Amplifier Setting screen.
8. Press the [AXIS] soft key, the [(OPRT)] soft key, and then the [SETING] soft key. The
setting will be complete after you turn the CNC OFF and then ON.
