Common settings of RISC board Additional Manual Page 11

Additional Manual
Title
No.
FANUC Series 16i /18i –MA/MB
Common setting of RISC board
A-78442E
Page
10/
15
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
・ Feed per revolution -G95
・ Constant surface speed control -G96,G97
・ Infeed control -G160,G161
Restriction -2
The following functions can not be used in the AI High Precision Contour Control mode,
the AI NANO High Precision Contour Control mode or the 5-axis control mode.
・ Flexible synchronous control
・ Sequence number comparison and stop
It is not possible to stop by the sequence number in the AI High Precision Contour
Control mode , in the AI Nano High Precision Contour Control mode or in the 5-
axis control mode.
・ Index table indexing
・ Retrace function
Do not use retrace function in the program which uses the AI High Precision
Contour Control mode or the AI Nano High Precision Contour Control or 5-axis
control mode.
・ Rotary axis control
・ Gentle curve normal direction control
・ Tool life management
Tool life value is counted in the AI High Precision Contour Control mode or in the
AI Nano AI High Precision Contour Control mode. However , do not use the
command related to the tool life management function.
・ Macro executor (Execution macro)
・ Manual handle interruption
・ Feedrate change of F1 digit feed by manual pulse generator
・ External deceleration (External deceleration is not aviailable )
Restriction –3
The following commands can not be used in the 5-axis control mode. The alarm is issued if
the function was used.
- M,S,T and B function with motion command
- NURBS interpolation -G6.2
- Workpiece coordinate system -G54-G59, G54.1
- Canned cycle - G73,G74,G76,
-G80～G89,G98,G99
- Manual interruption operaton
- Tool retract and recover
Restriction –4
In the 5-axis control mode, the following functions cannot be used, The warning message is
displayed on the screen when the following functions are used. :
- MDI intervention
