Common settings of RISC board Additional Manual Page 4

Additional Manual
Title
No.
FANUC Series 16i /18i –MA/MB
Common setting of RISC board
A-78442E
Page
3/
15
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
1 Common setting of RISC board
General
The following functions are executed at high speed with RISC processor.
• AI high precision contour control (FANUC Series 16i/18i-MA/MB)
• AI NANO high precision contour control (FANUC Series 16i-MA/MB)
• Tool center point control (FANUC Series 16i-MA/MB)
• Tool axis compensation in tool axis direction (FANUC Series 16i-MA/MB)
• 3-dimensional cutter compensation (FANUC Series 16i-MA/MB)
• 3-dimensional circular interpolation (FANUC Series 16i-MA/MB)
Expansion of RISC commnd
The parameter(No.19600#0-#5) setting expands the following functions which is executed
with RISC processor.
5-axis control mode
mode ON mode OFF
function
G51 G50 Scaling
G51.1 G50.1 Programmable mirror image
G54.2 Pn
(n=1-8)
G54.2 P0 Rotary table dynamic fixture offset
G68 G69 Coordinate system rotation
G68 I_J_K_ G69 3-dimensional coordinate system conversion
G41,G42 G40 Cutter compensation C
AI high precision contour control, AI NANO high precision contour control, Tool center
point control, Tool axis compensation in tool axis direction, 3-dimensional cutter
compensation and 3-dimensional circular interpolation can be used in the mode of above
mentioned functions when the above mentioned function is set to be executed with RISC
processor.
Please refer to paragraph of restrictions for the restriction in this case.
AI high precision contour control, AI NANO high precision contour control, Tool center
point control, Tool axis compensation in tool axis direction, 3-dimensional cutter
compensation and 3-dimensional circular interpolation can be used only when the state of
the above mentioned functions is canceling when the above mentioned function is set to be
executed with CNC.
The alarm(P/S5012) occurs if AI high precision contour control, AI NANO high precision
contour control, Tool center point control, Tool axis compensation in tool axis direction, 3-
dimensional cutter compensation and 3-dimensional circular interpolation is used when the
state of the above mentioned function is not canceling.
5-axis control mode
The state to execute the each function of AI high precision contour control, AI NANO high
precision contour control, Tool center point control, Tool axis compensation in tool axis
direction, 3-dimensional cutter compensation and 3-dimensional circular interpolation is
generically called five axis control mode.
The function set in the expansion of RISC command is included, too .
