Common settings of RISC board Additional Manual Page 13

Additional Manual
Title
No.
FANUC Series 16i /18i –MA/MB
Common setting of RISC board
A-78442E
Page
12/
15
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
1.4 The Function list which can be used
Item Specifications Note
Axis control
Controlled axes 3 axes
Controlled paths 1-path
Simultaneously controlled axes 2 axes
Controlled axis expansion Up to 8 axes
Simultaneously controlled axis
expansion
Up to 6 axes
Axis control by PMC The axis which is used in the AI High Precision Contour Control
mode or in the AI NANO High Precision Contour Control mode
can not be used as the control axis of the PMC Axis Control in the
AI High Precision Contour Control mode or in the AI NANO High
Precision Contour Control mode
Cs contour control The NANO interpolation and the Advanced preview feed-forward
function are canceled once when the command for Cs axis in AI
high precision contour control mode or AI NANO high precision
contour control mode
Axis name 3 basic axes: X,Y,Z; Additional axes:
U,V,W,A,B, or C
Twin table control Synchronized operation/individual operation/a normal drive
cannot be changed in the AI high precision contour control mode
or in the AI NANO high precision contour control mode Please
include all the twin table control axes to the maximum control axis
number (parameter No.7510) of RISC.
Simple synchronous control Synchronized operation/individual operation/a normal drive
cannot be changed in the AI high precision contour control mode
or in the AI NANO high precision contour control mode Please
include all the simple synchronous control axes to the maximum
control axis number (parameter No.7510) of RISC.
Least input increment 0.001mm,0.001deg,0.0001inch
Incremental System 1/10 0.0001mm,0.0001deg,0.00001inch
Inch/metric conversion Inch mode / metric mode cannot be changed in the AI high
precision contour control mode or in the AI NANO high precision
contour control mode.
Interlock All axes/each axis
Machine lock All axes/each axis
Emergency stop
Stored stroke check 1 The stroke limit cannot be set by the stroke limit external setting
signal in the AI high precision contour control mode or in the AI
NANO high precision contour control mode. Overrun on the OT
limit does not occur in the AI high precision contour control mode
or in the AI NANO high precision contour control mode.
Stored stroke check 2 The AI high precision contour control mode or the AI NANO high
precision contour control mode is automatically canceled once and
the buffering is inhibited if G22 or G23 is used in the AI high
Precision Contour Control mode or in the AI high Precision
Contour Control mode,
Mirror image Do not change the state of the signal in the AI High Precision
Contour Control mode or AI NANO High Precision Contour
Control mode.
Backlash compensation for each rapid
traverse and cutting feed
