Common settings of RISC board Additional Manual Page 5

Additional Manual
Title
No.
FANUC Series 16i /18i –MA/MB
Common setting of RISC board
A-78442E
Page
4/
15
　Newly registered　　　　　　　
Ver Date Design Description
01 01.03.16
Hosokawa
1.1 Signal
HPCC mode signal
MHPCC (F066#6)
[Classification] Output signal
[Function] Indicates that the system is set to the following functions mode
• AI high precision contour control
• AI NANO high precision contour control
• Tool center point control
• Tool axis compensation in tool axis direction
• 3-dimensional cutter compensation
• 3-dimensional circular interpolation
Indicates that the system is set to the following fucntions mode if the parameter
(No.19600#0-#5) setting expands the following functions which is executed with RISC
processor.
• 3-dimensional coordinate system conversion
• Programmable mirror image
• Scaling
• Coordinate system rotation
• Rotary table dynamic fixture offset
• Cutter compensation C
[Output condition] The signal is set to 1 in the following condition
• G05 P10000 is specified in a program.
(AI high precision contour control or AI NANO high precision contour control)
• G43.4 or G43.5 is specified in a program.
(Tool center point control)
• G43.1 is specified in a program.
(Tool axis compensation in tool axis direction)
• G41.2, G41.3 or G42.2 is specified in a program.
(3-dimensional cutter compensation)
• G2.4 or G3.4 is specified in a program.
(3-dimensional circular interpolation)
• G51 is specified in a program when the parameter RSC(No19600#0)=1
(Scaling)
• G51.1 is specified in a program when the parameter RMI(No19600#1)=1
(Programmable mirror image)
• G54.2Pn(n=1-8) is specified in a program when the parameter RFX(No19600#2)=1
(Rotary table dynamic fixture offset )
• G68 is specified in a program when the parameter RRO(No19600#3)=1
(Coordinate system rotation)
• G68I_J_K_ is specified in a program when the parameter R3D(No19600#4)=1
(3-dimensional coordinate system conversion)
