FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 13

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
１２/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table 5-5. Pc=2810W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
282 278 294 296 242 190 98 52
25%
705 703 698 721 759 693 633 619
35%
990 991 982 984 1043 969 1005 1051
50%
1416 1423 1417 1411 1410 1459 1553 1678
70%
2011 2009 2010 1997 2026 2094 2222 2352
90%
2607 2604 2597 2636 2696 2718 2772 2893
Table 5-6. Pc=3380W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
336 333 365 367 306 245 131 63
25%
842 840 846 891 929 866 792 755
35%
1187 1185 1190 1199 1287 1213 1241 1261
50%
1708 1707 1708 1710 1753 1836 1909 1999
70%
2423 2418 2424 2424 2487 2580 2681 2762
90%
3135 3137 3151 3177 3243 3251 3299 3373
Table 5-7. Pc=3940W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
394 393 429 430 372 306 170 76
25%
971 977 993 1046 1096 1059 962 898
35%
1387 1377 1392 1416 1551 1473 1471 1485
50%
1999 1987 2004 2018 2119 2235 2247 2292
70%
2824 2829 2849 2859 2960 3110 3139 3171
90%
3677 3680 3693 3725 3753 3767 3791 3865
Table 5-8. Pc=4500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
438 442 480 484 436 370 211 92
25%
1091 1092 1121 1178 1235 1208 1096 1038
35%
1566 1557 1588 1614 1733 1669 1669 1708
50%
2280 2263 2289 2305 2397 2527 2526 2636
70%
3245 3228 3245 3261 3386 3491 3516 3582
90%
4188 4199 4228 4272 4313 4313 4335 4382
