FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 14

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
１３/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table６ C5000-E standard data table and recommended area of pulse instruction
（A gray area where stability is confirmed is recommended. ）
Value in table：Feedback target value of pulse instruction (Unit:W)
Table 6-1. Pc=625W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
71 84 109 118 116 114 109 323
25%
180 193 223 255 309 330 359 643
35%
254 263 291 323 397 434 514 834
50%
359 366 391 418 506 577 707 1124
70%
497 497 520 547 643 733 913 1417
90%
634 631 656 697 840 958 1122 1571
Table 6-2. Pc=1250W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
136 143 163 180 177 173 157 348
25%
334 341 357 373 427 446 468 732
35%
463 472 484 498 552 584 670 968
50%
661 666 677 686 729 795 941 1324
70%
920 922 929 940 995 1065 1251 1692
90%
1179 1174 1186 1222 1343 1426 1558 1933
Table 6-3. Pc=1875W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
195 198 214 227 223 216 184 357
25%
477 481 486 498 547 566 580 823
35%
668 670 672 677 720 745 838 1111
50%
949 949 954 952 967 1038 1195 1533
70%
1324 1324 1322 1324 1372 1433 1620 1972
90%
1699 1692 1694 1735 1838 1896 2001 2303
Table 6-4. Pc=2500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
259 259 282 291 282 273 223 375
25%
636 638 643 657 709 722 725 943
35%
891 893 893 899 949 966 1056 1295
50%
1267 1269 1267 1270 1279 1388 1520 1801
70%
1771 1769 1767 1772 1828 1912 2062 2335
90%
2271 2269 2273 2321 2403 2443 2530 2764
