  2. FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function

FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 17

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
１６/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table 7-5. Pc=3750W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
352 375 356 244 0 0 0 0
25%
863 924 932 919 694 545 451 254
35%
1238 1294 1256 1238 1154 1121 995 765
50%
1805 1833 1805 1707 1928 1909 1735 1632
70%
2550 2555 2494 2470 2677 2682 2578 2527
90%
3254 3244 3258 3277 3296 3281 3277 3258
Table 7-6. Pc=4500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
422 474 483 365 127 0 0 0
25%
1046 1121 1167 1172 1004 887 789 568
35%
1515 1571 1542 1594 1670 1576 1436 1243
50%
2204 2232 2227 2171 2546 2476 2284 2209
70%
3095 3094 3066 3122 3418 3366 3235 3193
90%
3948 3952 4003 4050 4060 4041 4018 3999
Table 7-7. Pc=5250W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
502 567 595 487 230 84 0 0
25%
1248 1318 1430 1440 1360 1239 1136 910
35%
1810 1843 1861 1979 2134 2012 1876 1717
50%
2517 2630 2663 2686 3104 3024 2841 2781
70%
3681 3661 3647 3765 4106 4031 3910 3863
90%
4679 4683 4763 4809 4824 4791 4786 4763
Table 7-8. Pc=6000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
572 657 703 595 361 197 174 51
25%
1412 1505 1660 1707 1702 1595 1511 1314
35%
2082 2114 2175 2377 2546 2438 2373 2208
50%
3015 3005 3090 3291 3643 3568 3451 3371
70%
4234 4242 4294 4500 4805 4692 4622 4547
90%
5429 5471 5574 5573 5587 5541 5550 5522
