FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 16

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
１５/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table７ C6000-E standard data table and recommended area of pulse instruction
（A gray area where stability is confirmed is recommended. ）
Value in table：Feedback target value of pulse instruction (Unit:W)
Table 7-1. Pc=750W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
0 0 0 0 0 0 0 0
25%
145 145 93 0 0 0 0 0
35%
234 234 154 121 0 0 0 0
50%
342 356 262 187 98 0 0 0
70%
473 484 403 328 234 215 206 149
90%
632 641 510 538 524 501 510 486
Table 7-2. Pc=1500W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
127 126 0 0 0 0 0 0
25%
338 351 309 267 0 0 0 0
35%
483 516 436 403 178 0 0 0
50%
685 722 642 558 398 272 267 164
70%
966 1007 876 787 722 731 731 647
90%
1265 1260 1166 1176 1171 1162 1162 1124
Table 7-3. Pc=2250W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
202 210 145 0 0 0 0 0
25%
498 548 529 478 192 0 0 0
35%
708 764 712 684 436 296 207 0
50%
1018 1088 1031 942 811 816 704 563
70%
1463 1500 1416 1336 1332 1378 1313 1219
90%
1889 1880 1824 1838 1843 1833 1819 1791
Table 7-4. Pc=3000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
283 291 248 127 0 0 0 0
25%
695 745 740 694 436 254 189 0
35%
980 1045 989 956 764 713 587 366
50%
1426 1477 1415 1322 1332 1365 1229 1079
70%
2012 2044 1969 1898 1988 2044 1950 1885
90%
2597 2592 2569 2583 2588 2588 2583 2546
