  2. FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function

FANUC Series 16i/160i-LB,LPB Pulse Power Feedback Function Additional Manual Page 15

Additional Manual
EDIT
DATE DESIGN
DESCRIPTION
TITLE
Pulse Power Feedback Function
A-81053-080
Page
１４/16
01 04.09.14 M.Andou New registration
FANUC LTD
DR
A
W
No.
02 05.11.08 M.Andou Change of approx. power monitor
Table 6-5. Pc=3125W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
318 322 350 362 345 332 264 394
25%
788 793 804 838 886 893 882 1070
35%
1108 1108 1115 1131 1204 1206 1283 1495
50%
1574 1576 1583 1596 1628 1765 1858 2087
70%
2205 2203 2208 2219 2298 2407 2514 2718
90%
2823 2825 2841 2887 2957 2986 3061 3248
Table 6-6. Pc=3750W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
382 391 423 427 411 391 302 414
25%
947 954 972 1027 1072 1077 1038 1215
35%
1333 1333 1351 1386 1481 1458 1517 1710
50%
1901 1901 1917 1939 2026 2169 2203 2399
70%
2659 2657 2668 2696 2811 2923 2982 3132
90%
3408 3406 3438 3477 3529 3552 3597 3742
Table 6-7. Pc=4375W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
445 454 482 486 475 457 352 437
25%
1108 1108 1131 1172 1227 1236 1184 1368
35%
1560 1551 1579 1606 1708 1661 1722 1933
50%
2230 2223 2244 2267 2355 2467 2505 2719
70%
3127 3127 3143 3175 3300 3382 3425 3568
90%
4022 4024 4058 4099 4147 4149 4201 4310
Table 6-8. Pc=5000W table for pulse feedback (Unit:W)
10Hz 50Hz 150Hz 250Hz 500Hz 700Hz 1kHz 2kHz
10%
495 507 543 552 545 530 414 464
25%
1238 1238 1269 1324 1399 1413 1343 1549
35%
1746 1735 1772 1805 1937 1892 1949 2155
50%
2496 2489 2519 2548 2666 2791 2816 3009
70%
3509 3502 3529 3570 3713 3790 3829 3961
90%
4519 4519 4562 4601 4648 4653 4698 4789
