PROGRAMMING7. COORDINATE SYSTEM

B–63504EN/01

A coordinate system used for machining a workpiece is referred to as a

workpiece coordinate system. A workpiece coordinate system is to be set

with the NC beforehand (setting a workpiece coordinate system).

A machining program sets a workpiece coordinate system (selecting a

workpiece coordinate system).

A set workpiece coordinate system can be changed by shifting its origin

(changing a workpiece coordinate system).

A workpiece coordinate system can be set using one of three methods:

(1)Method using G50

A workpiece coordinate system is set by specifying a value after G50

in the program.

(2)Automatic setting

Workpiece coordinate system is automatically set when manual

reference position return is performed (see III–3.1.).

(3)Input using the MDI panel

Six workpiece coordinate systems can be set beforehand using the

MDI panel (see III–3.1.).

When an absolute command is used, a workpiece coordinate system

must be established in any of the ways described above.

G50 IP_

A workpiece coordinate system is set so that a point on the tool, such as

the tool tip, is at specified coordinates. If IP is an incremental command

value, the work coordinate system is defined so that the current tool

position coincides with the result of adding the specified incremental

value to the coordinates of the previous tool position. If a coordinate

system is set using G50 during offset, a coordinate system in which the

position before offset matches the position specified in G50 is set.

7.2

WORKPIECE

COORDINATE

SYSTEM

7.2.1

Setting a Workpiece

Coordinate System

Format

D Setting a workpiece

coordinate system by G50

Explanations
