Series 0i - TA Operators manual Page 212

Operators manual

Page of 714

/ 714

PROGRAMMING14. COMPENSATION FUNCTION

B–63504EN/01

188

This section describes the following operations when tool position offset

is applied: G53, G28, G30, and G30.1 commands, manual reference

position return, and the canceling of tool position offset with a T00

command.

Executing reference position return (G28) or a G53 command when tool

position offset is applied does not cancel the tool position offset vector.

The absolute position display is as follows, however, according to the

setting of bit 4 (LGT) of parameter No. 5002.

LGT = 0 (Tool geometry compensation is based on shift of the coordinate system.)

Tool geometry

compensation

Tool wear

compensation

Absolute posi-

tion coordinate

display

Block for reference position

return or G53 command

The shift is reflected. Coordinates

shifted according to the tool geom-

etry compensation are displayed.

The vector is not reflected. The

coordinates are displayed as if the

offset had been temporarily can-

celed.

Next block Coordinates shifted according to

the tool geometry compensation

are displayed.

The vector is reflected.

LGT = 1 (Tool geometry compensation is based on tool movement.)

Tool geometry

compensation

Tool wear

compensation

Absolute posi-

tion coordinate

display

Block for reference position

return or G53 command

The vector is not reflected. The

coordinates are displayed as if the

offset had been temporarily can-

celed.

The vector is not reflected. The

coordinates are displayed as if the

offset had been temporarily can-

celed.

Next block The vector is reflected. The vector is reflected.

NOTE

Bit 6 (DAL) of parameter No. 3104 is set to 0 (the actual positions to which the tool position offset

is applied are displayed in the absolute position display).

14.1.6

G53, G28, G30, and

G30.1 Commands

When Tool Position

Offset is Applied

Explanations

D Reference position

return (G28) and G53

command when tool

position offset is applied
