G. ALARM LIST

669

Number ContentsMessage

231 FORMAT ERROR IN G10 OR L50 Any of the following errors occurred in the specified format at the pro-

grammable–parameter input.

1 Address N or R was not entered.

2 A number not specified for a parameter was entered.

3 The axis number was too large.

4 An axis number was not specified in the axis–type parameter.

5 An axis number was specified in the parameter which is not an

axis type.

6 An attempt was made to reset bit 4 of parameter 3202 (NE9) or

change parameter 3210 (PSSWD) when they are protected by a

password. Correct the program.

233 DEVICE BUSY When an attempt was made to use a unit such as that connected via

the RS–232–C interface, other users were using it.

239 BP/S ALARM While punching was being performed with the function for controlling

external I/O units ,background editing was performed.

240 BP/S ALARM Background editing was performed during MDI operation.

244 P/S ALARM In the skip function activated by the torque limit signal, the number of

accumulated erroneous pulses exceed 32767 before the signal was

input. Therefore, the pulses cannot be corrected with one distribution.

Change the conditions, such as federates along axes and torque

limit, and try again.

245 T–CODE NOT ALOWED IN THIS

BLOCK

One of the G codes, G50, G10, and G04, which cannot be specified

in the same block as a T code, was specified with a T code.

247 ILLEGAL CODE USED FOR

OUTPUT

When an encrypted program is output, EIA is set for the punch code.

Specify ISO.

5010 END OF RECORD The end of record (%) was specified.

5018 POLYGON AXIS SPPED ERROR The rotating speed ratio of the command value cannot be maintained

in the G51.2 mode , because the spped of the spindle or the polygon

turning synchronous axis exceeds the clamp value or itis too slow.

5020 PARAMETER OF RESTART ERROR An erroneous parameter was specified for restarting a program.

5059 RADIUS IS OUT OF RANGE During circular interpolation, the center of the arc specified with I, J,

and K caused the radius to exceed nine digits.

5073 NO DECIMAL POINT A decimal point is not specified for a command for which a decimal

point must be specified.

5074 ADDRESS DUPLICATION ERROR The same address has been specified two or more times in a single

block. Alternatively, two or more G codes in the same group have

been specified in a single block.

5195 DIRECTION CAN NOT BE JUDGED When the touch sensor with a single contact signal input is used in the

direct input B function for tool offset measurement values, the stored

pulse direction is not constant. One of the following conditions exists:

· The stop state exists in offset write mode.

· Servo off state

· The direction varies.

· Movement takes place simultaneously along two axes.

5257 G41/G42 NOT ALLOWED IN MDI

MODE

G41/G42 (cutter compensation C: M series, tool–nose radius com-

pensation: T series) was specified in MDI mode. (Depending on the set-

ting of bit 4 of parameter No. 5008)
