Series 0i - TA Operators manual Page 706

Operators manual

Page of 714

/ 714

APPENDIXG. ALARM LIST

B–63504EN/01

682

10) System alarms

(These alarms cannot be reset with reset key.)

Number Message Contents

900 ROM PARITY FROM and SRAM modules parity error in a ROM file (control soft-

ware), such as CNC, macro, or digital servo. The FROM and SRAM

modules may be defective.

910 DRAM PARITY : (Low) DRAM parity error

911 DRAM PARITY: (High)

The main board may be defective.

912 SRAM PARITY: (Low) SRAM parity error.

Perform operation for clearing all memory. If the error recurs, re-

913 SRAM PARITY : (High)

Perform operation for clearing all memory. If the error recurs, re-

place the FROM & SRAM module or memory & spindle module.

Subsequently, set the parameters and all other data again.

920 SERVO ALARM (1/2 AXIS) Servo alarm (1st or 2nd axis). A watchdog alarm or a RAM parity

error in the servo module occurred.

Replace the servo control module on the main CPU board.

921 SERVO ALARM (3/4 AXIS) Servo alarm (3rd or 4th axis). A watchdog alarm or a RAM parity

error in the servo module occurred.

Replace the servo control module on the main CPU board.

924 SERVO MODULE SETTING

ERROR

The digital servo module is not installed.

Check that the servo control module on the main board is mounted

securely.

930 CPU INTERRUPUT CPU error (abnormal interrupt)

The main board is faulty.

940 PCB ERROR PCB ID error. The main board or the memory module may be

defective.

950 PMC SYSTEM ALARM Fault occurred in the PMC. The PMC control module on the main

board or the RAM module may be defective.

960 DC24V POWER OFF The abnormal 24VDC input power may be defective.

971 NMI OCCURRED IN SLC An alarm condition occurred in the interface with an I/O unit.

Check the connection between the PMC control module on the main

board and the I/O Unit. Also, check that the power of the I/O Unit is

on and that the interface module is operating normally.

973 NON MASK INTERRUPT NMI occurred for an unknown reason.

The printed board of the power unit or the main board may be defec-

tive. Or, there may be noise interference.

974 BUS ERROR Bus error

The main board may be defective.
