1. DISPLAY AND OPERATION

Function Operation

Function

key

Mode

SETTING

PWE=1

KEY

PMC parameterLadder program

input

Only when

PMC

Emergency

stop

DGNOS /

PARAM

DGNOS screen → No. → FileNumber →

READ

Data type is automaticallyidentified.

(The baud rate is fixed to 4800 bps.)

PMC parameter output EDIT DGNOS /

PARAM

PMC parameter display → No. → File number

→ WRITE

Ladder program output – DGNOS /

PARAM

DGNOS screen → No. RFile number →

WRITE

Switching of 1–path mode (Power Mate i–D) and 2–path mode (Power Mate i–D2)

Function

KEY

SETTING

PWE=1

Mode

Function

key

Operation

Select Single path control

system to Dual paths control

system

Power ON _

S and 2

Select Dual paths control

system to Single path control

system

Power ON _

S and 1

NOTE

1 When above mentioned operation is done, all CNC data on the SRAM memory back–upped

by a battery, such as tool offset data, macro variable and so on, are cleared and the parameters

are set the default value at shipping. So all CNC data should be set again.

2 Even when the above mentioned operation is done, the special parameters are not cleared.

3 The operation to select path control system should be done only when required. This operation

is not necessary at every power–on.

4 Even if you keep pushing both 2 and S keys during turning on power on the condition of

2 paths control system or keep pushing both 1 and S keys on the condition of 1 path control

system, SRAM data is also all cleared.

5 After the memory all clear operation, the selection data for path control is set to 1–path control

system.

Switching between the 1–path mode and 2–path mode (Power Mate i–D2)

Classification Function

KEY

SETTING

PWE=1

Mode

Function

key

Operation

Path Change 2 path side to 1 path side _

H and 2

1 path side to 2 path side _

H and 1
