1. DISPLAY AND OPERATION

B–63175EN/03

File operation from the FANUC Handy File

Function

KEY

SETTING

PWE=1

Mode

Function

key

Operation

Searching a file for its beginning EDIT PROG

→ FILE No. → [ ] → [F SRH] →

[EXEC]

Deleting a file OFF EDIT PROG

→ FILE No. → [ ] → [F DELETE] →

[EXEC]

Verifying a program EDIT PROG Searching a file for its beginning →

→ Program No. → [(OPRT)] → [ ] →

[READ] → [EXEC]

Registration from FANUC Handy File

Function

KEY

SETTING

PWE=1

Mode

Function

key

Operation

Inputting parameters f Emergency

stop

SYSTEM

(PARAM)

[(OPRT)] → [ ] → [READ] → [EXEC]

Inputting PMC parameters f Emergency

stop

SYSTEM

(PMC)

[ ] → [I/O]→ (CHANNEL NO)

→ (DEVICE NAME) [FDCAS] →

(KIND OF DATA) [PARAM] → [READ] →

(FILE NO) File No . → [EXEC]

INPUT

Inputting ladder programs f Emergency

stop

SYSTEM

(PMC)

[ ] → [I/O]→ (CHANNEL NO)

→ (DEVICE NAME) [FDCAS] →

(KIND OF DATA) [LADDER] → [READ] →

(FILE NO) File No . → [EXEC]

INPUT

Inputting offset data OFF EDIT OFFSET After searching the begining of file

[(OPRT)] → [ ] → [READ] → [EXEC]

Registration of programs OFF EDIT PROG

→ FILE No. → INPUT → [ ] →

[READ] → [EXEC]

Macro variable data input OFF EDIT PROG

N → FILE No. → INPUT → [ ] → O →

Program No. → [READ] → [EXEC]

AUTO PROG

START
