Series 16i/18i/160i/180i/160is/180is - MA Operators manual Page 774

Operators manual
OPERATION8. DATA INPUT/OUTPUT B–63014EN/02
754
When this screen is displayed, the program data item is selected. The soft
keys for other screens are displayed by pressing the rightmost soft key
(next–menu key). Soft key [M–CARD] represents a separate
memory card function for saving and restoring system RAM data. (See
Sections 8.10.7 and Section NO TAG.)
MACRO (OPRT)WORKPITCH
(OPRT)M–CARD
When a data item other than program is selected, the screen displays only
a file directory.
A data item is indicated, in parentheses, on the title line.
READ/PUNCH (PARAMETER)
No. FILE NAME SIZE DATE
O0001 N00001
0001 O0222 332010 96/04/06
0002 O1003 334450 96/05/04
0003 MACROVAR.DAT 653400 96/05/12
0004 O0003 334610 96/05/04
0005 O0001 334254 96/06/04
0006 O0002 333750 96/06/04
0007 CNCPARAM.DAT 334453 96/06/04
~ ~
Program directory display does not match bit 0 (NAM) of parameter No.
3107, or bit 4 (SOR) of parameter No. 3107.
Display the following soft keys with soft key
[(OPRT)].
F SRH DELETEN READF READ PUNCH
The operation of each function is the same as on the directory (memory
card) screen. Soft key
[O SET], used for program number setting, and the
”PROGRAM NUMBER =” indication are not displayed for data items
other than program.
[F SRH] : Finds a specified file number.
[F READ] : Reads a specified file number.
[PUNCH] : Writes a file.
[N READ] : Reads a file under a specified file name.
[DELETE] : Deletes a specified file number.
NOTE
With a memory card, RMT mode operation and the
subprogram call function (based on the M198 command)
cannot be used.
Explanations
D Each data item
D Program directory
display
D Using each function
