Series 16i/18i/160i/180i/160is/180is - MA Operators manual Page 895

Operators manual
OPERATION
B–63014EN/02
11. SETTING AND DISPLAYING DATA
875
OFFSET 01234 N12345
No. GEOMETRY (MACHINE)
001 100.000 X–12345.678
002 200.000 Y–12345.678
003 300.000 Z–12345.678
004 400.000 A–12345.678
005 500.000 B–12345.678
006 600.000 C–12345.678
007 700.000 U–12345.678
008 800.000 V–12345.678
009 900.000 (T) 12345678
010 –999.999 (M) 12345678
(HM) –12345.678
>
JOG **** *** *** ALM 13:14:15 OFST
OFFSET SETTING WORK (OPRT)
Tool length offset measurement screen for tool offset memory A
OFFSET 01234 N12345
No. GEOMETRY WEAR (MACHINE)
001 100.000 100.000 X–12345.678
002 200.000 200.000 Y–12345.678
003 300.000 300.000 Z–12345.678
004 400.000 400.000 A–12345.678
005 500.000 500.000 B–12345.678
006 600.000 600.000 C–12345.678
007 700.000 700.000 U–12345.678
008 800.000 800.000 V–12345.678
009 900.000 900.000 (T) 12345678
010 –999.999 –999.999 (M) 12345678
(HM) –12345.678
>
JOG **** *** *** ALM 13:14:15 OFST
OFFSET SETTING WORK (OPRT)
Tool length offset measurement screen for tool offset memory B
OFFSET 01234 N12345
(LENGTH) (MACHINE)
No. GEOMETRY WEAR X–12345.678
001 100.000 100.000 Y–12345.678
002 200.000 200.000 Z–12345.678
003 300.000 300.000 A–12345.678
004 400.000 400.000 B–12345.678
005 500.000 500.000 C–12345.678
006 600.000 600.000 U–12345.678
007 700.000 700.000 V–12345.678
008 800.000 800.000 (T) 12345678
009 900.000 900.000 (M) 12345678
010 –999.999 –999.999 (HM) –12345.678
>
JOG **** *** *** ALM 13:14:15 OFST
OFFSET SETTING WORK (OPRT)
Tool length offset measurement screen for tool offset memory C
