1.2 Setting of a name of the spindle position and the wait
position
The spindle position and the wait position are displayed by the number such
as 11, 12, 13 etc. at MG item of the tool management data table screen.
This function displays user’s setting name of any 3 characters set by G10
command.
Format
Format
G10L77P4; Setting of a name of the spindle and the wait position
mode
N_;
P_R_;
G11; Mode cancel
Meaning of command
N_: Number of the spindle position or the wait position
P_: Character number(1 to 3)
R_: Character code(ASCII)
Explanation
· Spindle or wait position(N_)
Specify the spindle position or the wait position for changing name.
Specification value is the following table.
Spindle position
1
st
2
nd
3
rd
4
th
1
st
path 111 112 113 114
2
nd
path 211 212 213 214
3
rd
path 311 312 313 314
Wait position
1
st
2
nd
3
rd
4
th
1
st
path 121 122 123 124
2
nd
path 221 222 223 224
3
rd
path 321 322 323 324
· Character number(P_)
Specify the charcter number.
・ The displayed name is 3 characters or less.
・ If a number of setting character is less than 3, set 0 as a character code to
remaining data.
· Character code(R_)
Specify the character code for the spindle positon or the wait position name.
・ The data of the character code is only ASCII code.
・ The data of the character code is not checked.
Edit
12/26
Data Signature
Description
FANUC Series 16i/18i/21i-MB/TB
Expansion Tool Management Function
A-79171
Drawing No.
Title
Page
Previous page
Next page
