FS 16i/18i/21i-MB/TB, Expansion Tool Management Function Additional Manual Page 14

Additional Manual
2003.6.30
1.3 Setting of the customizing data with the decimal point
This function can set customizing data with the decimal point by G10
command
Format
Format
G10L77P5; Specify the decimal point to the customizing data
N_R_;
G11; Mode cancel
Meaning of command
N_: Number of the customizing data( 1 to 20)
R_: Set value(0 to 7)
Explanation
· Number of the customizing
data(N_)
Specify the number of a customizing data with a decimal point.
· Set value(R_)
Specify the decimal point ( 0 to 7).
If the setting value is 0, the customizing data does not have a decimal point.
NOTE
・ When G10 L77 P5 is normal termination, the power must be turned off
before operation is continued.
・ It is possible to input value below decimal point by MDI key only.
Example
Setting 3 digits below decimal point for the customizing data1 and data2
G10L77P5; Specify the decimal point to customizing data
N1 R3; Specify 3 digits below decimal point of the
customizing data1
N2 R3; Specify 3 digits below decimal point of the
customizing data2
G11; Mode cancel
Edit
14/26
Data Signature
Description
FANUC Series 16i/18i/21i-MB/TB
Expansion Tool Management Function
A-79171
Drawing No.
Title
Page
Previous page
Next page
