FS 16i/18i/21i-MB/TB, Expansion Tool Management Function Additional Manual Page 7

Additional Manual
2003.6.30
NOTE
When G10 L77 P3 is normal termination, the power must be turned off before
operation is continued.
Example
1.In case of 12 softkey type, tool compensasion memory A.
G10L77P3; Customization of the tool management data table
screen
N1 R1; No. 1 is No.
N2 R2; No. 2 is TYPE-NO.
N3 R3; No. 3 is MG.
N4 R4; No. 4 is POT.
N5 R5; No. 5 is T-INFO.
N6 R6; No. 6 is L-COUNT.
N7 R7; No. 7 is MAX-LIFE.
N8 R8; No. 8 is NOTICE-L.
N9 R9; No. 9 is L-STATE.
N10 R11; No. 10 is F(Feedrate).
N11 R21; No. 11 is D.
N12 R22; No. 12 is OFFSET-M.
N13 R80; No. 13 is CUSTOM0.
N14 R81; No. 14 is CUSTOM1.
N15 R-1; Terminated.
G11; Mode cancel
The tool management data table screen is displayed as order of “NO.,
TYPE-NO., MG, POT, L-INFO, L-COUNT, MAX-LIFE, NOTICE-L,
L-STATE” at the 1
st
page, “F, D, OFFSET-M, CUSTOM0, CUSTOM1” at
the 2
nd
page.
Edit
7/26
Data Signature
Description
FANUC Series 16i/18i/21i-MB/TB
Expansion Tool Management Function
A-79171
Drawing No.
Title
Page
Previous page
Next page
