  2. FANUC Series 16i/18i-TB Batch CNC Data Input/Output Function with a Memory Card Specifications

FANUC Series 16i/18i-TB Batch CNC Data Input/Output Function with a Memory Card Specifications Additional Manual Page 12

Additional Manual
Dec.09,02 T.Nakazato
EDIT
Apprv.DESIG.
12
／
12
DATE DESIG.
DESCRIPTION
DATE
FANUC Series 16i
/
18i-TB
Batch CNC data input/output function
with a memory card
Ａ
-76509
TITLE
DRAW.NO.
SHEET
4. Notice
１） For using this function, it is necessary to set parameter No.138#0=1.
２） The operation of this function can be executed only on the ALL IO screen.
３） The operation of this function is available only in path-1.
４） The operation of this function can be executed only on EDIT mode.
５） This function is available only with a memory card.
６） The operation of this function can be executed only in the foreground. It can not be in the
background.
７） The output data are outputted as independent files of each path, and the files have
individual names.
８） To read and punch can not be executed with the arbitrary file name.
９） If there is the file to have the same name when punch executes, it is overwritten.
１０） If an error occurred on the way to read and punch, the files of the paths after when the
error occurred are not inputted and outputted.
１１） If this function and the batch input/output function of 2 paths’ programs (Parameter
No.3023#4=1) were used at the same time, the batch input/output function of 2 paths’
programs is invalid.
