Select which data (part programs, parameters, offset data, custom macros) is inputtted and
outputted by the above soft key on 5, 6.
Part program, Parameters, Offset data Custom macros
１．Select item １．Press soft key [+]
２．Press soft key [(OPRT)] ２．Press soft key [MACRO]
３．Press soft key [+] ３．Press soft key [(OPRT)]
４．Select [A.READ] or [A.PNCH] ４．Press soft key [A.PNCH]
５．Select [CAN] or [EXEC] ５．Select [CAN] or [EXEC]
│<│ PRGRM │ PARAM │OFFSET│ │(OPRT)│+│
│<│ PRGRM │ PARAM │OFFSET│ │(OPRT)│+│
│<│ PRGRM │ PARAM │OFFSET│ │(OPRT)│+│
│<│ MACRO │ │ │ │(OPRT)│+│
│<│ F SRH │F READ│N READ│PUNCH │DELETE│+│
│<│ MACRO │ │ │ │(OPRT)│+│
│<│A.PNCH │A.READ │ │ │ │+│
│<│ F SRH │A.PNCH │ │PUNCH │DELETE│+│
│<│ │ │ │ CAN │ EXEC │ │
│<│ │ │ │ CAN │ EXEC │ │
