Series 0i/0i Mate - Model B Parameter manual Page 123

Parameter manual

Page of 346

/ 346

B–63840EN/03

4. DESCRIPTION OF PARAMETERS

115

This parameter specifies the period that must elapse before the screen

clear function is applied. If 0 is set, the screen is not cleared.

Moreover, this parameter is valid only when it is set on the path 1 side.

D083124

D07

D06

D05

D04

D03

D02

D01

D163125 D15 D14 D13 D12 D11 D10 D09

D243126 D23 D22 D21 D20 D19 D18 D17

3127 D25

[Data type] Bit

Dxx (xx: 01 to 25) When modal G code is displayed on the program check screen, the xx

group G code is:

0 : Displayed.

1 : Not displayed.

NOTE

Set these parameters when using the display with seven soft

keys.

3131 Subscript of each axis name

[Data type] Byte axis

This parameter specifies a subscript (one character) of each axis name

with a code.

NOTE

For characters and codes, see the correspondence table in

Appendix A.

[Example] If the configuration of axes is X, Z, C and Y when the following settings

are made, the names of the axes are indicated as XA, Z1, CS, and Y1,

respectively.

(1) Setting

Parameter 3131x 65 (A). . . . . . . .

Parameter 3131z 49 (1). . . . . . . .

Parameter 3131c 83 (S). . . . . . . .

Parameter 3131y 0 (1). . . . . . . .

3132 Axis name (absoulute coordinate) for current position display

3133 Axis name (relative coordinate) for current position display

[Data type] Byte axis

[Valid data range] 0 to 255
