Series 0i/0i Mate - Model B Parameter manual Page 321

Parameter manual

Page of 346

/ 346

B–63840EN/03

4. DESCRIPTION OF PARAMETERS

313

8133

#6 #5 #4

SYC

MSP

SCS

AXC

SSC

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

[Data type] Bit

SSC Constant surface speed control is

0 : Not used.

1 : Used.

AXC Spindle positioning is

0 : Not used.

1 : Used.

SCS Cs contouring control is

0 : Not used.

1 : Used.

MSP Multi spindle control is

0 : Not used.

1 : Used.

SYC Spindle synchronous control is

0 : Not used.

1 : Used.

NOTE

Spindle positioning and Cs contouring control by serial

spindle cannot be selected at the same time.

8134

#6 #5 #4 #3 #2 #1

BAR

IAP

NOTE

When this parameter is set, the power must be turned off

before operation is continued.

[Data type] Bit

IAP Conversational programming with graphic function is

0 : Not used.

1 : Used.

BAR Chuck and tail stock barrier is

0 : Not used.

1 : Used.

NOTE

When Chuck and tail stock barrier is selected, Stored stroke

check 2 and 3 cannot be used.
