FS16i/18i/21i - TB/MA/MB Additional Manual Page 91

Additional Manual
FANUC Series 16i/18i/21i-MA/MB/TB TOOL MANAGEMENT FUNCTION A-78614EN
2002.08.08 Edition 04
91
13250 Valid number of spindle position
[Data type] Byte
[Valid data range] 0 to 4
Sets the number of the spindle position valid for tool management
function.
13251 Valid number of wait position
[Data type] Byte
[Valid data range] 0 to 4
Sets the number of the wait position valid for tool management
function.
13252 Specific tool specifying M code
[Data type] Word
[Valid data range] 0, 1 to 65535
Sets the M code which specifies specific tool not by tool type number
but by T code directly.
13260 Customizing data number for search target
[Data type] Byte
[Valid data range] 0 to 20
Sets customizing data number for search target when the parameter
SWC (No.13203#6) is 1.
The enabled data is 1∼
∼∼
∼4 or 1∼
∼∼
∼20(when the additional customized data
on tool management function option is effective).
If the parameter SWC (No13203#6) is set to 0, or this parameter value
is invalid, the search function by customizing data is unavailable. In this
case the most shortest life tool is searched normally.
NOTE
- This parameter is only for i-series model B.
